Sliding Door
ORDER CODE Tray Size Tray Finish Adjustment: Min-Max Recess Handing Door Opening A panel B panel C panel Glass Type
S6S10 1000mm 950-990 Reversible 375 500 435 Standard Clear
AS10BBR 1000mm 950-990 Reversible 375 506 404 Standard Clear
AS10MB 1000mm 950-990 Reversible 375 506 404 Standard Clear
AS11BBR 1100mm 1050-1090 Reversible 425 556 454 Standard Clear
S6S11 1100mm 1050-1090 Reversible 475 506 404 Standard Clear
AS11MB 1100mm 1050-1090 Reversible 425 556 454 Standard Clear
AS12MB 1200mm 1150-1190 Reversible 475 606 504 Standard Clear
S6S12 1200mm 1150-1190 Reversible 575 600 535 Standard Clear
AS12BBR 1200mm 1150-1190 Reversible 475 606 504 Standard Clear
AS14BBR 1400mm 1350-1390 Reversible 575 706 604 Standard Clear
AS14MB 1400mm 1350-1390 Reversible 575 706 604 Standard Clear
S6S14 1400mm 1350-1390 Reversible 580 700 635 Standard Clear
S6S15 1500mm 1450-1490 Reversible 695 706 704 Standard Clear
S6S16 1600mm 1550-1590 Reversible 795 706 804 Standard Clear
AS17MB 1700mm 1650-1690 Reversible 575 706 904 Standard Clear
AS17BBR 1700mm 1650-1690 Reversible 575 706 904 Standard Clear
S6S17 1700mm 1650-1690 Reversible 895 706 904 Standard Clear
Side Panel
ORDER CODE Tray Size Tray Finish Adjustment: Min-Max with Side Panel
ASP76BBR 760mm 730-750
S6SP76 760mm 710-750
ASP76MB 760mm 730-750
ASP80BBR 800mm 770-790
ASP80MB 800mm 770-790
S6SP80 800mm 770-790
ASP90BBR 900mm 870-890
ASP90MB 900mm 870-890
S6SP90 900mm 870-890
ASP10MB 1000mm 970-990
S6SP10 1000mm 970-990
ASP10BBR 1000mm 970-990
S6SP12 1200mm 1170-1190

Left hand

Right hand

Note:

Left-handed enclosures open to the left, right-handed enclosures to the right.

All of our trays are reversible, bar our offset quadrants.

The perfect fit shower tray

Complete your enclosure with a shower tray designed to fit

Choose from our luxurious handcrafted Truestone slate trays in a choice of designer colours or minimalist and ultra slim Level 25 trays to add a contemporary feel to any bathroom.

Stunning shower enclosures

Choose your bathroom centre-piece

MERLYN showers combine timeless elegance and superior quality, down to the very last detail. Choose from Chrome or Colour and multiple door opening and size options.
