1 Door Quadrant
ORDER CODE Tray Size Wetroom Adjustment: min-max recess Opening A panel B panel Glass Type Price (Incl VAT) Price (Excl VAT)
AR81Q800L 800mm 770 x 790 430 210 510 Standard Clear €1,415.00 €1,150.41
AR81Q800R 800mm 770 x 790 430 210 510 Standard Clear €1,415.00 €1,150.41
AR81Q900R 900mm 870 x 890 470 310 570 Standard Clear €1,538.00 €1,250.41
AR81Q900L 900mm 870 x 890 470 310 570 Standard Clear €1,538.00 €1,250.41
AR81Q1000R 1000mm 970 x 990 470 410 670 Standard Clear €1,661.00 €1,350.41
AR81Q1000L 1000mm 970 x 990 470 410 670 Standard Clear €1,661.00 €1,350.41
1 Door Offset Quadrant
ORDER CODE Tray Size Wetroom Adjustment: min-max recess Opening A panel B panel Glass Type Price (Incl VAT) Price (Excl VAT)
AR81Q976L 900 x 760mm 870 - 890 / 730 - 750 415 310 490 Standard Clear €1,538.00 €1,250.41
AR81Q976R 900 x 760mm 870 - 890 / 730 - 750 415 310 490 Standard Clear €1,538.00 €1,250.41
AR81Q1080L 1000 x 800mm 970 - 990 / 770 - 790 430 610 510 Standard Clear €1,661.00 €1,350.41
AR81Q1080R 1000 x 800mm 970 - 990 / 770 - 790 430 410 510 Standard Clear €1,661.00 €1,350.41
AR81Q1280R 1200 x 800mm 1170 - 1190 / 770 - 790 430 610 510 Standard Clear €1,722.00 €1,400.00
AR81Q1280L 1200 x 800mm 1170 - 1190 / 770 - 790 430 610 510 Standard Clear €1,722.00 €1,400.00
AR81Q1290L 1200 x 900mm 1170 - 1190 / 870 - 890 470 610 570 Standard Clear €1,784.00 €1,450.41
AR81Q1290R 1200 x 900mm 1170 - 1190 / 870 - 890 470 610 570 Standard Clear €1,784.00 €1,450.41
AR81Q1480R 1400 x 800mm 1370 - 1390 / 770 - 790 571 804 504 Standard Clear €1,968.00 €1,600.00
AR81Q1480L 1400 x 800mm 1370 - 1390 / 770 - 790 571 804 504 Standard Clear €1,968.00 €1,600.00

Left hand

Right hand

Note:

Left-handed enclosures open to the left, right-handed enclosures to the right.

All of our trays are reversible, bar our offset quadrants.

The perfect fit shower tray

Complete your enclosure with a shower tray designed to fit

Choose from our luxurious handcrafted Truestone slate trays in a choice of designer colours or minimalist and ultra slim Level 25 trays to add a contemporary feel to any bathroom.

Stunning shower enclosures

Choose your bathroom centre-piece

MERLYN showers combine timeless elegance and superior quality, down to the very last detail. Choose from Chrome or Colour and multiple door opening and size options.

SPEAK TO THE MERLYN TEAM TO DISCUSS YOUR REQUIREMENTS

Get in touch to discuss your requirements
