10 Series 1 Door Offset Quadrant

Description

Beautifully curved toughened glass combined with an exceptionally smooth roller action allows this door to glide silently open and closed.

Features

Height: 2000mm

Up to 10mm toughened glass

Easy clean Mershield StayClear protected glass

Lifetime Guarantee

Handle options available – Eyelet handle with chrome eyelet option and circular filler plate option

Quiet closing

Door handed – Order Left Hand (LH) or Right Hand (RH)

Wetroom compatible

Downloads

Brochure: The Irish Collection Brochure

Download View all Brochure

(7.68 MB)
Data Sheets: 10 Series 1 DOOR OFFSET QUAD Data Sheets

Download View all Data Sheets

(925.85 kB)
Instructions: Series 10 quadrant fitting instruction

Download View all Instructions

(4.99 MB)

Series 10 quadrant fitting instruction New handle

Download View all Instructions

(4.99 MB)

Warranty terms and conditions

To show our utmost confidence in the quality of our products we offer the MERLYN Lifetime Guarantee.

To avail of the lifetime guarantee please register your product within 28 days of purchase and you will be issued of a guarantee number which you need to keep – register for your Guarantee online here.

Note: If you do not have an email address then please post in a copy of your proof of purchase with your personal details and our customer care team will register your product for you. Send to MERLYN, Unit 8 Purcellsinch Industrial Estate, Old Dublin Road, Kilkenny, R95 HP71, Ireland.

*some exclusions may apply

Care instruction

Atleast once per week give your shower some TLC. Use a microfiber cloth, add some hot water to clean the glass, then wring the cloth out tight and wipe down glass (and don’t forget to dry) – no cleaning product needed. The tray should be cleaned regularly with hot soapy water and a soft cloth / soft brush and then dried off. Do not use scourers, abrasives or chemical cleaners. The use of hydrochloric acid in any ratio should not be used as this may discolour the tray surface.

Product Questions

Customer Questions

No Questions

Did you find what you were looking for?

Your question:

I agree to the MERLYN Privacy Policy

Your name:

get notification on email when the answer is ready

Your e-mail:

1 Door Offset Quadrant

ORDER CODE	Tray Size	Wetroom Adjustment: min-max recess	Tray Finish Adjustment: Min-Max Recess	Door Opening	B panel	C panel	Glass Type
M103233CL	1000 x 800mm	955 - 975, 755 - 775	975 - 995;775 - 795	435-340	435	520	Standard Clear
M103243CR	1200 x 800mm	1155 - 1175, 755 - 775	1175 - 1195;775 - 795	435-340	635	520	Standard Clear
M103243CL	1200 x 800mm	1155 - 1175, 755 - 775	1175 - 1195;775 - 795	435-340	635	520	Standard Clear
M103241CL	1200 x 900mm	1155 - 1175, 855 - 875	1175 - 1195;875 - 895	485-390	635	570	Standard Clear
M103241CR	1200 x 900mm	1155 - 1175, 855 - 875	1175 - 1195;875 - 895	485-390	635	570	Standard Clear
M10148HL	1400 x 800mm	1355 - 1375, 755 - 775	1375 - 1395, 775 - 795	435-340	835	520	Standard Clear
M10148HR	1400 x 800mm	1355 - 1375, 755 - 775	1375 - 1395, 775 - 795	435-340	835	520	Standard Clear

1 Door Quadrant

ORDER CODE	Tray Size	Wetroom Adjustment: min-max recess	Tray Finish Adjustment: Min-Max Recess	Door Opening	B panel	C panel	Glass Type
M103211CL	800mm	775 - 795	775 - 795	435-340	235	535	Standard Clear
M103211CR	800mm	775 - 795	775 - 795	435-340	235	535	Standard Clear
M103221CL	900mm	875 - 895	875 - 895	485-390	340	575	Standard Clear

Left hand

Right hand

Note:

Left-handed enclosures open to the left, right-handed enclosures to the right.

All of our trays are reversible, bar our offset quadrants.
